Product Information
The Commercial Sensor Drive Solar Light is a cost effective smart option to meet your lighting needs.
It can be mounted onto an existing light pole and the mains powered street lighting is converted into a commercial off-grid lighting system. It can also be tailored to have poles designed for the required project.
The system allows to be installed anywhere in remote off grid regions to inner city suburban locations.
It is perfect for, car parks, pathways, jetties, and for general public safety lighting. Components being the highest quality as per the specifications below, designed in Australia to meet our most demanding climate conditions.
Suitable Site Locations
- Council parks
- Public walkways
- Parking bays
- Construction sites
- Mine sites
- Government depots
- Caravan parks
- Jetties
- School and university campuses
Specifications
| Power Consumption (light) | 40 Watt, 60 Watt |
| Power Generation (solar) | 60 Watt, 90 Watt, |
| Lifetime | 74,000 hour LED rating Philips Cree |
| Light Output (max) | 40W: 5600 lumens 60W: 8400 lumens |
| Colour Temperature | Cool White 4000K – 5700K |
| Light Control | Pre-programmed MPPT controller or Pre-programmed time control |
| Lighting Modes | Smart drive motion sensor or pre-programmed time-based mode for constant output mode with lighting time function. |
| Beam Pattern | IES Type III |
| Battery Rating | 27Ah 42Ah (all 12.8V+) |
| Battery Chemistry | Lithium-ion Phosphate LiFePO4 (L10) |
| Battery Runtime | Up to 38 hours in dim mode via sensor drive operation |
| Recharge Time | 5-6 hours in daytime |
| Protection | IP66 rated, IK10 impact protection |
| Operating Temperatures | -20°C to +60°C |
| Dimensions | 40W: 1158 mm x 281 mm x 56 mm 60W: 1158 mm x 405 mm x 56 mm |
| Weight | 40W = 17.5 kg, 60W = 22 kg |
| Material | Die-cast aviation grade aluminium body, monocrystalline silicon solar cells with PC Lens. |
| Installation | Option to self-install with provided accessories through Asten Solar install guide or Asten Solar to do project works to completion. |
| Warranty | 5 year fitting. |
| Product Identifiers | Commercial sensor drive, Philips CREE LED, CRI>75, Type III lens, L10 Lithium Phosphate, Sensor Drive or time control operation. |
