Hybrid Wind / Solar Street Light

Dual Energy Source For Power Around The Clock

The Hybrid Solar Street Light: within our LED solar lighting range, the Wind Turbine combined with our Photovoltaic array gives the system a solution for high altitude regions – harvesting energy via UV & wind technology

The AST-1782P is our solar array LED solar lighting system which operates via UV & wind turbine power. This system is suitable for colder climates – within this range it is a stand-alone solution that can be customised to meet continued lighting suitable for its geographical location.

Both systems have full MPPT remote management operation and offer significant savings both on installation cost and no ongoing expense. It makes sense to look at the benefits of renewable energy and the immediate return on investment.

Both systems can be configured to meet site location requirements be it turbine combined with solar or solar array for 11,200LM or 14,000LM.

Applications

The Hybrid Solar Light is ideally suited for:

Cold climate (sub-zero temperatures)
Roadways
Roads
Port terminals
Intersections
Parking bays
Industrial sites
High Altitude tourist locations

Enquire about this product

Enquire now

Specifications

Power Consumption (light)	100 Watt
Power Generation (Turbine) Photovoltaic Array (Solar)	250 Watt, DC24V with lower speed wind start up, fen design. 90 Watt, DC12V x 2 operational +/-
Lifetime	74,000 hour LED rating Philips Cree
Light Output (max)	100W: 14,000 lumens
Colour Temperature	Cool White 4000K – 5700K
Light Control	Hybrid MPPT controller with Pre-programmed time control (24V)
Lighting Modes	Smart drive motion sensor or pre-programmed time-based mode for constant output mode with lighting time function.
Beam Pattern	IES Type III
Battery Rating	130Ah x 2 (all 12.8V+)
Battery Chemistry	Lithium-ion Phosphate LiFePO4 (L10) (Gel) deep cycle
Recharge Time	5-6 hours in daytime (3 days secure back up power)
Protection	IP66 rated
Operating Temperatures	-20°C to +60°C
Bird Spikes	Anti perching spikes are designed to protect against “fouling” spikes can be mounted at the highest point of panel array. This ensures that birds are unable to perch on the solar panels and allowing the optimum efficiency.
Warranty	5 year fitting warranty
Product Identifiers	Commercial sensor drive, Philips CREE LED, CRI>75, Type III lens, L10 Lithium Phosphate, Sensor Drive or time control operation, Hybrid commercial Charge Controller.

Power Consumption (light)	80 Watt
Power Generation (Turbine) Photovoltaic Array (Solar)	200 Watt, DC24V with lower speed wind start up, fen design. 75 Watt, DC12V x 2 operational +/-
Lifetime	74,000 hour LED rating Philips Cree
Light Output (max)	80W: 11,200 lumens
Colour Temperature	Cool White 4000K – 5700K
Light Control	Hybrid MPPT controller with Pre-programmed time control (24V)
Lighting Modes	Smart drive motion sensor or pre-programmed time-based mode for constant output mode with lighting time function.
Beam Pattern	IES Type III
Battery Rating	120Ah x 2 (all 12.8V+)
Battery Chemistry	Lithium-ion Phosphate LiFePO4 (L10) (Gel) deep cycle
Recharge Time	5-6 hours in daytime (3 days secure back up power)
Protection	IP66 rated
Operating Temperatures	-20°C to +60°C
Bird Spikes	Anti perching spikes are designed to protect against “fouling” spikes can be mounted at the highest point of panel array. This ensures that birds are unable to perch on the solar panels and allowing the optimum efficiency.
Warranty	5 year fitting warranty
Product Identifiers	Commercial sensor drive, Philips CREE LED, CRI>75, Type III lens, L10 Lithium Phosphate, Sensor Drive or time control operation, Hybrid commercial Charge Controller.
